Handles BG
Material and surface:
Handle shank and ledge of extruded aluminium AlMgSi 0.5; glass ball blasted and natural colour or black anodized with satin finish. Clamping sleeves of stainless steel.
Due to design constraints, dimension L may vary.
Note:
Other handle lengths and colour versions available on request.
Stress resistance:
min. 1000 N.
show more show less
|
Unit of measure
|
|||
|---|---|---|---|
| Type | |||
| A | L |
Anodizing version natural-colored with satin finish
Order-No. |
Anodized aluminum black with satin finish
Order-No. |
| A | L |
Anodizing version natural-colored with satin finish
Order-No. |
Anodized aluminum black with satin finish
Order-No. |
|---|---|---|---|
| A 250 | L ca. 305 |
Anodizing version natural-colored with satin finish
Order-No. BG-35.A305.11 3D+CAD |
Anodized aluminum black with satin finish
Order-No. BG-35.A305.14 3D+CAD |
| A 400 | L ca. 455 |
Anodizing version natural-colored with satin finish
Order-No. BG-35.A455.11 3D+CAD |
Anodized aluminum black with satin finish
Order-No. BG-35.A455.14 3D+CAD |
| A 600 | L ca. 655 |
Anodizing version natural-colored with satin finish
Order-No. BG-35.A655.11 3D+CAD |
Anodized aluminum black with satin finish
Order-No. BG-35.A655.14 3D+CAD |
